The OSMO Recessed Ceiling Plaster Frame fan coil offers a super slim solution for a ceiling-mounted fan coil. The concealed frame ensures only the cover panel is visible, providing a clean, minimal profile, paintable design ideal for discerning clients and demanding architects.
Compatible with low-temperature generators such as heat pumps, condensing boilers, and solar-integrated systems.
| Model | RCP4 | RCP8 | RCP10 | RCP12 | RCP14 |
|---|---|---|---|---|---|
| L (in) | 13.9 | 22.7 | 30.6 | 38.5 | 46.3 |
| Model | RCP4 | RCP8 | RCP10 | RCP12 | RCP14 |
|---|---|---|---|---|---|
| L (mm) | 353 | 577 | 777 | 978 | 1176 |
| Model | RCP4 | RCP8 | RCP10 | RCP12 | RCP14 |
|---|---|---|---|---|---|
| L (in) | 14.9 | 22.7 | 30.6 | 38.5 | 46.4 |
| Model | RCP4 | RCP8 | RCP10 | RCP12 | RCP14 |
|---|---|---|---|---|---|
| L (mm) | 378 | 577 | 777 | 978 | 1179 |
| Model | RCP4 | RCP8 | RCP10 | RCP12 | RCP14 |
|---|---|---|---|---|---|
| L (in) | 20.6 | 28.5 | 36.4 | 44.3 | 52.2 |
| Aesthetic panel (in) | 30.4 | 38.3 | 46.1 | 54 | 61.9 |
| Model | RCP4 | RCP8 | RCP10 | RCP12 | RCP14 |
|---|---|---|---|---|---|
| L (mm) | 523 | 724 | 925 | 1125 | 1326 |
| Aesthetic panel (mm) | 772 | 973 | 1171 | 1372 | 1572 |
| RCP4 | RCP8 | RCP10 | RCP12 | RCP14 | |
|---|---|---|---|---|---|
| Total (MBh) | 3.1 | 7.2 | 9.6 | 11.3 | 12.7 |
| Sensible (MBh) | 2.5 | 5.9 | 7.2 | 9.2 | 9.9 |
| Water flow (GPM) | 41.5 | 96.4 | 127.6 | 150.0 | 168.5 |
| Pressure (Ft H2O) | 4.0 | 2.7 | 5.7 | 6.0 | 7.1 |
| RCP4 | RCP8 | RCP10 | RCP12 | RCP14 | |
|---|---|---|---|---|---|
| Capacity (MBh) | 3.5 | 7.5 | 10.3 | 13.0 | 14.7 |
| Water flow (GPM) | 46.2 | 100.4 | 137.1 | 173.0 | 196.3 |
| Pressure (Ft H2O) | 3.0 | 3.1 | 6.4 | 7.1 | 7.8 |
| RCP4 | RCP8 | RCP10 | RCP12 | RCP14 | |
|---|---|---|---|---|---|
| High (CFM) | 86 | 173 | 258 | 334 | 390 |
| Medium (CFM) | 53 | 124 | 187 | 241 | 282 |
| Low (CFM) | 29 | 69 | 106 | 145 | 154 |
| Static pressure (In W.C.) | 0.04 | 0.04 | 0.05 | 0.05 | 0.05 |
| RCP4 | RCP8 | RCP10 | RCP12 | RCP14 | |
|---|---|---|---|---|---|
| Total (kW) | 0.9 | 2.1 | 2.8 | 3.3 | 3.7 |
| Sensible (kW) | 0.7 | 1.7 | 2.1 | 2.7 | 2.9 |
| Water flow (L) | 157.1 | 364.9 | 483.0 | 567.8 | 637.8 |
| Pressure (kPa) | 12.0 | 8.1 | 17.0 | 17.9 | 21.2 |
| RCP4 | RCP8 | RCP10 | RCP12 | RCP14 | |
|---|---|---|---|---|---|
| Capacity (kW) | 1.0 | 2.2 | 3.0 | 3.8 | 4.3 |
| Water flow (L) | 174.9 | 380.1 | 519.0 | 654.9 | 743.1 |
| Pressure (kPa) | 9.0 | 9.3 | 19.1 | 21.2 | 23.3 |
| RCP4 | RCP8 | RCP10 | RCP12 | RCP14 | |
|---|---|---|---|---|---|
| High (m³/h) | 146 | 294 | 438 | 567 | 663 |
| Medium (m³/h) | 90 | 211 | 318 | 409 | 479 |
| Low (m³/h) | 49 | 117 | 180 | 246 | 262 |
| Static pressure (Pa) | 10 | 10 | 12 | 12 | 12 |
